-Lying combustion chamber separate with boiler -Material for combustion chamber : Coal, firewood, cashew shell -Automatic supplying water by relays – Temperature Spreading : 14,2 m2
2
Stain steel water filter DN50
2 units
-Cast iron main body. -Stain steel 304, 316 filter. – Pressure 10,16kgf/cm2. – Impurities filter -Made in Taiwan
3
Vertical Water Pump
2 units
-Body pump coverred by stain steel. – Pump body made by alloy cast iron – Pump chamber made by stainless alloy AISI 304 – Made in China – Electric consumption : 3.7kw
4
Steam supplying Valve DN100-PN16
3 units
-Cast iron main body and connection parts that made they are fixed to each other. -Made in Poland
5
Safety Valve DN50
1 unit
-Cast iron main body and connection parts that made they are fixed to each other. -Made in Italy
6
Pressure Clock 0-15kg/cm2
2 units
-Measure pressure of steam – Made in Korea
7
Pressure Pelays
2 units
– Volume 0-10kgs/cm2. – Balance steam function
8
Sucking Fan
1 unit
Capacity 15 HP – Invester Controlling – Dust sucking function in combustion chamber
9
Blowing Fan
1 unit
Capacity 5 HP – Invester Controlling – Blowing air for burning fuel
10
Electric cabinet
1 unit
LG branding, controlling all parts of Boiler
Cargo decription :
Boiler dust cleaning tank that make smoke reach pure before enterring environment
Boiler bottle stored steam before supplying to equipments
This product does not incldue Water tank for Supplying water to Boiler
